特点
•The rotor is supported on two bearings, whereas these bearings are on the same side in relation to the rotor (balanced).
•The supplier provide the equipment with a metal base which will allow CUSTOMER to build a flat concrete base (with neither housing fittings nor bearing overhangs).
•The equipment will be supplied fully assembled on its metal base.
•The shaft design allow the disassembly of the two bearings on the coupling side without the need of disassembling the rotor.
参数
| 型号 | 特殊设计 | 基础安排 | 钢结构 |
| 电机功率 | 15KW~ 1000KW or larger | 带锚固螺栓的混凝土地基 | |
| 驱动类型 | 通过耦合直接 | 可选配件 | 过滤器、消音器、膨胀节 |
| 叶轮尺寸 | Up to 2600mm | 入口/出口风门 | |
| 尺寸 | 特殊设计 | 气动/电动执行机构 | |
| 流量 | Up to 500,000 m3/h | 轴承监测仪器 | |
| 压力 | 高达 30,000Pa | 材料 | 碳钢/不锈钢 |
| 气体温度 | -20~500℃ | 冷却类型 | 空气/水 |
| 速度 | 最高 3600RPM | 密封件类型 | Labyrinth / Carbon ring |
| 频率 | 50/60Hz | HS 编码 | 841459 |
| 电压 | 380V/440V/465V/6000V | 标准 | GB/ASME/ISO/CE/IEC/NEMA |
